Features

Carbonated soft drink filling machine
Design for glass bottle filling with metal crown cap, with filling speed range 2000bph-18000bph at 500ml glass bottle.
Bottle range: 330ml-1500ml glass bottle

Technical Parameter

型号 Model	RIFC16/12/6G	RIFC18/18/6G	RIFC24/24/8G	RIFC32/32/10G	RIFC40/40/12G	RIFC50/50/15G
冲瓶头数 Rinsing Head	16	18	24	32	40	50
灌装头数 Filling Head	12	18	24	32	40	50
封口头数 Capping Head	6	6	8	10	12	15
生产能力 Capacity (500ml)	2000BPH	4000BPH-6000BPH	6000BPH-8000BPH	8000BPH-10000BPH	10000BPH-13000BPH	13000BPH-16000BPH
气源气压 Pressure of air source	0.7Mpa	0.7Mpa	0.7Mpa	0.7Mpa	0.7Mpa	0.7Mpa
耗气量 Air consumption	0.25M3/min	0.8M3/min	0.8M3/min	0.8M3/min	0.8M3/min	1M3/min
冲洗水压力 Pressure of rinse water	0.2~0.25MPa	0.2~0.25MPa	0.2~0.25MPa	0.2~0.25MPa	0.2~0.25MPa	0.2~0.25MPa
冲洗水耗用量 Consumption of rinsing water	1t/hour	1.2t/hour	1.2t/hour	2t/hour	2t/hour	3t/hour
灌装方式 Filling method	Isobar Filling	Isobar Filling	Isobar Filling	Isobar Filling	Isobar Filling	Isobar Filling
适用瓶型 Suitable bottle size	H:150-300mm	H:150-320mm; D:Φ50-100mm; can be customized	H:150-320mm; D:Φ50-100mm; can be customized	H:150-320mm; D:Φ50-100mm; can be customized	H:150-320mm; D:Φ50-100mm; can be customized	H:150-320mm; D:Φ50-100mm; can be customized
装机容量 Power	2.5KW	3.5KW	4.5KW	5.6KW	6.3KW	7.5KW
重量 Weight	3000KG	3500KG	4500KG	5500KG	7000KG	9000KG
包装尺寸 Packing Size (LWH)(mm)	2200×1800×2300	2300×2000×2300	3000×2200×2800	4000×2600×2800	4700×2950×2800	5100×4800×3000
